2

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the water.

Display shows: H,

6 and On/O LED is

blinking rapidly

No water in the water supply or the tap is closed.

Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwa-

sher and reboot.

The sieve in the water inlet hose is clogged;

it is necessary to clean it

After having carried out the verication and cleaning, turn o and turn on the

dishwasher and restart a new program.

Dishwasher nishes the

cycle prematurely. Display

shows: 15 and On/O

LED is blinking rapidly

Drain hose positioned too low or siphoning

into home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check

for siphoning into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues

please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period

of either up to 7 or up to 10 years, according to the specic Regulation requirements.

TROUBLESHOOTING

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-

sales Service, please state the codes provided on your product‘s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model

identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

:

Please scan the QR code on your product in order to have more detailed information.

400011662622

02/2023 dk - Xerox Fabriano

DELAY -The start of the program may be delayed for a period of time

between 1 and 12 hours.

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

HALF LOAD - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent.

Remember to halve the amount of detergent.

Please scan the QR code on your product in order to have more detailed information.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address: dw_test_suppor[email protected]

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

CUTLERY BASKET

The basket is equipped with top

grilles for

improved cutlery arrangement.

The cutlery basket

should be positioned only at the front of the

lower rack.

Knives and other utensils with sharp edges

must be placed in the cutlery basket with the

points facing downwards or they must be

positioned horizontally in the tip-up com-

partments on the upper rack.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

1

A

2

A

B

3

C

4

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

UPPER RACK

(loading example for the

upper rack)

Load delicate and light

dishes: glasses, cups, saucers,

low salad bowls.

LOWER RACK

(loading example for the lower rack)

For pots, lids, plates, salad bowls, cutlery etc.. Lar-

ge plates and lids should ideally be placed at the

sides to avoid interferences with the spray arm.

The lower rack has tip-up supports which can be

used in a vertical position when arranging plates

or in a horizontal position (lower) to load pans and

salad bowls easily.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION
