Original Instructions

■ Use extreme caution when lifting or tilting the product for

maintenance, cleaning, storage, or transportation. The

blade is sharp; keep all body parts away from the blade

while it is exposed.

■ For transportation in vehicles, remove the isolator key

and the battery pack, and secure the product against

movement or falling to prevent injury to persons or

damage to the product.

TRANSPORTING LITHIUM BATTERIES

Transport the battery in accordance with local and national

provisions and regulations.

Follow all special requirements on packaging and labelling

when transporting batteries by a third party. Ensure that

no batteries can come in contact with other batteries

or conductive materials while in transport by protecting

exposed connectors with insulating, non-conductive caps or

tape. Do not transport batteries that are cracked or leaking.

Check with the forwarding company for further advice.

MAINTENANCE

■ Use only original manufacturer’s replacement parts,

accessories, and attachments. Failure to do so can cause

possible injury, can contribute to poor performance, and

may void your warranty.

■ Servicing requires extreme care and knowledge

and should be performed only by a qualified service

technician. Have the product serviced by an authorised

service centre only.

■ You may make adjustments and repairs described in this

manual. For other repairs, have the product serviced by

an authorised service centre only.

■ Turn off the product, and remove the isolator key and the

battery pack. Make sure that all moving parts have come to

a complete stop before any cleaning or maintenance task.

■ Check all nuts, bolts, and screws at frequent intervals

for proper tightness to ensure that the product is in safe

working condition.

■ After each use, clean the plastic parts with a soft, dry

cloth. Any part that is damaged should be properly

repaired or replaced by an authorised service centre.

■ Replace damaged blades and bolts in sets to preserve

balance.

■ Be careful during adjustment of the product to prevent

entrapment of the fingers between moving blades and

fixed parts of the product.

■ The blade on the product is sharp. Use extreme caution,

and wear heavy-duty gloves when fitting, replacing,

cleaning, or checking bolt security.

■ The blade bolts must be adequately tightened. See the

manufacturer’s recommendations for blade bolt torque,

which can be found in the product specification table in

this manual.

■ Be aware that even though the power source is turned

off, the blades can still be moved.

CLEARING BLOCKAGES

■ Turn off the product, and remove the isolator key and the

battery pack. Make sure that all moving parts have come

to a complete stop.

■ Always wear heavy-duty gloves when checking or

clearing a blockage. The blades are sharp, and the

blockage itself could be a sharp object.

■ Remove the grass catcher. Check and carefully clear the

grass catcher for obstructions.

■ Check the grass discharge chute, and carefully clear

blockages.

■ Turn the product on its side. Check its underside and the

area around the blade. Carefully remove any blockages.

Remember that the blade may move during cleaning.

KNOW YOUR PRODUCT

See page 137.

1. Self-propel speed slider

2. On/off trigger

3. Start button

4. Self-propel lever

5. Fold lever

6. One-touch folding handles

7. Fuel gauge

8. Grass catcher

9. Battery door

10. Height adjustment lever

11. Side discharge chute cover

12. Rear wheel

13. Front wheel

14. Side discharge chute

15. Mulching plug

16. Isolator key

17. Operator's manual

18. Battery pack

19. Charger

SYMBOLS ON THE PRODUCT

Safety alert

Read and understand all instructions

before operating the product. Follow all

warnings and safety instructions.

Wear ear protection.

Wear eye protection.

Do not operate the product on inclines

greater than 15°. Mow across the face of

slopes, never up and down.

Do not expose the product to rain or

damp conditions.

Keep hands and feet away from the

blades. Remove the battery pack before

maintenance.

Keep hands and feet away from the

blades. Keep hands and feet out of

openings while the product is running.
