12

Replace all fuel tanks and container caps securely.

Before tipping the lawn mower to maintain the blade or

drain oil, remove fuel from tank.

WARNING: Never fill fuel tank indoors, with

engine running or until the engine has been allowed to

cool for at least 15 minutes after running.

7-2 TO START ENGINE AND ENGAGE

BLADE

1. The unit is equipped with a rubber boot over the end of

the spark plug, make certain the metal loop on the end

of the spark plug wire (inside the rubber boot) is

fastened securely over the metal tip on the spark plug.

2. When starting cool or warm engine, turn throttle choke

lever at anywhere between “ ” position to “ ”

position. When operating, turn throttle choke lever to

“ ” position. (Fig. 22)

3. Standing behind the unit, grasp the brake control

handle and hold it against the upper handle as shown

in Fig. 23.

4. Grasp the starter handle as shown in Fig. 23 and pull

up rapidly. Return it slowly to the rope guide bolt after

engine starts.

Release the brake control handle to stop the engine and

blade.

Start the engine carefully according to

instructions and with feet well away from the

blade.

Do not tilt the lawn mower when starting the

engine. Start the mower on a level surface, free

of high grass or obstacles.

Keep hands and feet away from the rotating

parts. Do not start the engine when standing in

front of the discharge opening.

7-3 OPERATION PROCEDURES

During operation, tightly hold the brake handle with both

hands.

Note: During operation, when the brake handle is

released, the engine will stop and thus stopping the lawn

mower from operating.

Warning: In order to avoid any unintentional

start-ups of the lawn mower, it comes equipped with an

engine brake which must be pulled back before the

engine can be started. When the engine control lever is

released it must return to its initial position, at which point

the engine automatically switches off.

Note: Engine brake (brake handle): Use the lever

to stop the engine. When you release the lever the engine

and the blade stop automatically. To mow, hold the lever in

the working position. Before you start to mow, check the

start/stop lever several times to be sure that it is working

properly. Ensure that the tension cable can be smoothly

operated (i.e. is not catching or kinking in any way).

7-4 TO STOP ENGINE

CAUTION: The blade continues to rotate for a

few seconds after the engine is shut off.

1. Release the brake control handle to stop the engine

and blade. (Fig. 24)

2. Disconnect and ground the spark plug wire as

instructed in the separate engine manual to prevent

accidental starting while equipment is unattended.

7-5 CONNECTION FOR AUTO MOVE

The mower is equipped with a speed adjusting system

which can adjust 3 speeds from 3.0 km/h to 4.5 km/h.

Position “ ”: the slowest position; Position “ ”: the

fastest position. (Fig. 25)

The step as below:

1. Release the self-drive control handle until the lawn

mower does not go forward.

2. Adjust the appropriate speed which you want.

3. Grasp the self-drive control handle to go on mowing.

(Fig. 26)

CAUTION: Your mower is designed to cut normal

residential grass of a height no more than 250 mm.

Do not attempt to mow through unusually tall dry or wet

grass (e.g., pasture) or piles of dry leaves. Debris may

build up on the mower deck or contact the engine exhaust

presenting a potential fire hazard.

7-6 FOR THE BEST RESULTS WHEN

MOWING

Clear lawn of debris. Be sure that the lawn is clear of

stones, sticks, wire or other foreign objects which could be

accidentally thrown out by the mower in any direction and

cause serious personal injury to the operator and others

as well as damage to property and surrounding objects.

Do not cut wet grass. For effective mowing do not cut wet

grass because it tends to stick to the underside of the

deck preventing proper mowing of the grass clippings. Cut

no more than 1/3 the length of the grass. The

recommended cut for mowing is 1/3 the length of the

grass. Ground speed will need to be adjusted so the

clippings can be dispersed evenly into the lawn. For

especially heavy cutting in thick grass it may be

necessary to use one of the slowest speeds in order to get

a clean well mowed cut. When mowing long grass you

may have to cut the lawn in two passes, lowering the

blade another 1/3 of the length for the second cut and

perhaps cutting in a different pattern than was used the

first time. Overlapping the cut a little on each pass will

also help to clean up any stray clippings left on the lawn.

The mower should always be operated at full throttle to

get the best cut and allow it to do the most effective job of

mowing. Clean underside of deck. Be certain to clean the

underside of the cutting deck after each use to avoid a

build-up of grass, which would prevent proper mulching.

Mowing leaves. The mowing of leaves can also be

beneficial to your lawn. When mowing leaves make sure

they are dry and are not laying too thick on the lawn. Do

not wait for all the leaves to be off the trees before you

mow.
