English - 31 -

To change volume: Increase the volume by pushing

the button up. Decrease the volume by pushing the

button down.

To change channel: Press the middle of the button,

the information banner will appear on the screen.

Scroll through the stored channels by pushing the

button up or down.

To change source: Press the middle of the button

twice(for the second time in total), the source list will

appear on the screen. Scroll through the available

sources by pushing the button up or down.

To turn the TV off: Press the middle of the button

down and hold it down for a few seconds, the TV will

turn into standby mode.

Notes:

 If you turn the TV off, this circle starts again beginning

with the volume setting.

 Main menu OSD cannot be displayed via control

button.

Operation with the Remote Control

Press the Menu button on your remote control to

display main menu screen. Use the directional buttons

to select a menu tab and press OK to enter. Use the

directional buttons again to select or set an item. Press

Return/Back or Menu button to quit a menu screen.

Input Selection

Once you have connected external systems to your

TV, you can switch to different input sources. Press the

Source button on your remote control consecutively

to select the different sources.

Changing Channels and Volume

You can change the channel and adjust the volume

by using the Volume +/- and Programme +/- buttons

on the remote.

Inserting the Batteries into the Remote

Remove the screw that

secure the battery

compartment cover on

the back side of the

remote control first.

Remove the cover

gently. Insert two AAA

batteries. Make sure the (+) and (-) signs match (observe

correct polarity). Do not mix old and new batteries.

Replace only with same or equivalent type. Place the

cover back on. Then screw the cover back on again.

Connect Power

IMPORTANT: The TV set is designed to operate on

220-240V AC, 50 Hz socket. After unpacking, allow the

TV set to reach the ambient room temperature before

you connect the set to the mains. Plug the power cable

to the mains socket outlet.

Antenna Connection

Connect the aerial or cable TV plug to the AERIAL

INPUT (ANT) socket or satellite plug to the SATELLITE

INPUT (LNB) socket located on the back of the TV.

satellite

rear side of

the TV

aerial

or

cable

/LFHQVH1RWL¿FDWLRQ

The terms HDMI and HDMI High-

'H¿QLWLRQ0XOWLPHGLD,QWHUIDFHDQG

the HDMI Logo are trademarks or registered

trademarks of HDMI Licensing Administrator, Inc. in

the United States and other countries.

Manufactured under license from Dolby Laboratories.

Dolby, Dolby Audio and the double-D symbol are

trademarks of Dolby Laboratories.

YouTube and the YouTube logo are trademarks of

Google Inc.

For DTS patents, see http://patents.

dts.com. Manufactured under

license from DTS Licensing Limited.

DTS, the Symbol, & DTS and the Symbol together are

registered trademarks, and DTS TruSurround is a

trademark of DTS, Inc.

©

DTS, Inc. All Rights Reserved.

For DTS patents, see http://

patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, DTS-HD, the Symbol, & DTS or DTS-HD

and the Symbol together are registered trademarks of

DTS, Inc.

©

DTS, Inc. All Rights Reserved.

This product contains technology subject to certain

intellectual property rights of Microsoft. Use or

distribution of this technology outside of this product

is prohibited without the appropriate license(s) from

Microsoft.

Content owners use Microsoft PlayReady™ content

access technology to protect their intellectual property,

including copyrighted content. This device uses

PlayReady technology to access PlayReady-protected

content and/or WMDRM-protected content. If the

device fails to properly enforce restrictions on content

usage, content owners may require Microsoft to revoke

the device’s ability to consume PlayReady-protected

content. Revocation should not affect unprotected

English - 32 -

content or content protected by other content access

technologies. Content owners may require you to

upgrade PlayReady to access their content. If you

decline an upgrade, you will not be able to access

content that requires the upgrade.

Information for Users on Disposal of Old Equipment

and Batteries

[European Union only]

Products

Battery

Equipment bearing these

symbols should not be disposed

as general household waste.

You should look for appropriate

recycling facilities and systems

for the disposal of these

products.

Notice: The sign Pb below the symbol for batteries indicates

that this battery contains lead.

:LUHOHVV/$17UDQVPLWWHU6SHFL¿FDWLRQV

Frequency Ranges Max Output Power

2400 - 2483,5 MHz (CH1-CH13) < 100 mW

5150 - 5250 MHz (CH36 - CH48) < 200 mW

5250 - 5350 MHz (CH52 - CH64) < 200 mW

5470 - 5725 MHz (CH100 -

CH140)

< 200 mW

Country Restrictions

7KLVGHYLFHLVLQWHQGHGIRUKRPHDQGRI¿FHXVHLQDOO

EU countries (and other countries following the rele-

vant EU directive) without any limitation except for the

countries mentioned below.

Country Restriction

Bulgaria

General authorization required for outdoor

use and public service

France In-door use only for 2454-2483.5 MHz

Italy

If used outside of own premises, general

authorization is required

Greece

In-door use only for 5470 MHz to 5725

MHz band

Luxembourg

General authorization required for network

and service supply(not for spectrum)

Norway

Radio transmission is prohibited for the

geographical area within a radius of 20 km

from the centre of Ny-Ålesund

Russian Fed-

eration

In-door use only

The requirements for any country may change at any

time. It’s recommended that user checks with local

authorities for the current status of their national reg-

ulations for both 2.4 GHz and 5 GHz wireless LAN’s.
