- Always check the appliance before you use it. Do not
use the appliance if it is damaged, as this may cause
injury. Always replace a damaged part with one of
the original type.
Caution
- This appliance is not washable. Never immerse the
appliance in water and do not rinse it under the
tap (Fig. 1).
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only be
used by one person.
- Never use compressed air, scouring pads, abrasive
cleaning agents or aggressive liquids such as petrol
or acetone to clean the appliance.
- Only operate the appliance on 1.5V LR6 AA
batteries.
- Use and store the appliance at a temperature
between 15°C and 35°C.
- Do not expose the appliance to direct sunlight.
- Remove batteries from the appliance if you are not
going to use it for some time.
Electromagnetic elds (EMF)
- This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic elds.
General
- Maximum noise level: Lc = 75dB(A)
Preparing for use
Placing the batteries
1 Open the battery holder and put the batteries into
the battery holder. (Fig. 2)
Make sure your hands are dry when inserting
the batteries.
Make sure the + and - poles of the batteries point in the
right direction.
2 Close the battery holder.
Using the appliance
When you trim for the rst time, be careful and test the
appliance on a small part of your arm or leg. Do not
move the trimmer too fast, make smooth and gentle
movements.
Trimming with comb
1 Slide the comb to the desired hair length (Fig. 3).
The hair length in millimeters appears in the window in
the centre of the comb.
Note: When you trim for the rst time, start at the highest
length setting to familiarise yourself with the appliance.
2 Switch on the appliance.
ENGLISH
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benet from the support that Philips
offers, register your product at www.philips.com/
welcome.
Important safety information
Read this important information carefully before you use
the appliance and its accessories and save it for future
reference. The accessories supplied may vary for different
products.
Warning
- This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
3 Place the trimmer on the skin.
4 Move the trimmer slowly over the skin against
the direction of the hair growth while pressing it
lightly (Fig. 4).
Make sure the at surface of the comb always stays in
contact with the skin.
If a lot of hair has accumulated in the comb:
1 Make sure the appliance is switched off.
2 Slide the comb to the highest setting and
pull it off the appliance (Fig. 5).
Never pull off the comb at the exible top part, always
pull it off at the bottom part.
3 Blow and/or shake the hairs out of the comb (Fig. 6).
Trimming without comb
Use the trimmer without comb to trim full bears and
single hairs.
Note: The comb keeps the cutting unit at a certain distance
from the skin. If you use the trimmer without comb, the hair
will be cut off at the point where the cutting unit touches
the hair.
1 Switch on the appliance.
2 Make well-controlled movements. Touch the hair
lightly with the trimmer. (Fig. 7)
Cleaning
Never use compressed air, scouring pads, abrasive
cleaning agents or aggressive liquids such as petrol
or acetone to clean the appliance.
1 Switch off the appliance.
2 If the comb is on the appliance, pull it off.
3 Flip the cutting unit open.
4 Clean the cutting unit and the hair chamber with
the brush supplied. (Fig. 8)
5 Close the cutting unit by pushing it back onto the
appliance (‘click’).
Replacement
If the cutting unit is damaged or worn, always replace it
with the original Philips cutting unit.
1 Flip the cutting unit open.
2 Remove the old cutting unit by pulling it upwards.
3 Place the two lugs of the new cutting unit into the
guiding slots. (Fig. 9)
4 Push the cutting unit onto the appliance
(‘click’) (Fig. 10).
4222.002.8634.1
BT1005, BT1000
Register your product and get support at
www.philips.com/welcome
1
1
2
2
1
2
1,5
3
5
7
3
4
3
5
7
1
2
5 6
7
1
2
8
9
10
11 12
